CodeContext: Low-Latency Neural Code Search Engine

Ship a production-grade neural code search stack—ColBERT late interaction for token-level MaxSim matching, AST/Tree-sitter chunking across languages, Redis semantic cache for sub-10ms hits, plus RAGAS evaluation and OpenLLMetry traces behind FastAPI.

Advanced neural retrieval optimizing the tradeoff between ColBERT interaction depth and system throughput with Redis + FastAPI.

ragatouilleredisfastapipython-astdockeropenllmetry

You'll Build:

Neural Code Intelligence Engine

Techniques Covered:

T01Custom AST Parsing for structural code chunking and function-level indexing.
T02Late Interaction (ColBERT) for fine-grained, token-sensitive code search.
T03Semantic Caching (Redis) to accelerate recurrent architectural queries.
T04Evaluate performance with RAGAS and trace via OpenLLMetry to profile bottlenecks.

Production Goals

G01Minimize retrieval latency to sub-100ms for real-time developer workflows.
G02Achieve high recall on specific code patterns (e.g., middleware logic, retry policies).
G03Instrument the retrieval path with RAGAS metrics and OpenLLMetry span traces.

CodeContext: Low-Latency Neural Code Search Engine

The Project Kit

The Retrieval Pipeline

A modular Python codebase structured for production code intelligence:

AST / Tree-sitter Chunking: Structural function- and class-level indexing across py, js, ts, go, and more—with regex and sliding-window fallbacks.
ColBERT Late Interaction: Token-level MaxSim scoring via RAGatouille / PyLate for fine-grained code matching that bi-encoders miss.
Redis Semantic Cache: Sub-10ms cache hits for recurrent architectural queries with TTL write-back after ColBERT inference.
RAGAS + OpenLLMetry: Context precision/recall evaluation and span-level traces across Redis lookup and retrieval.

The Full-Stack Serving Layer

An entire system to index repositories and serve low-latency search:

FastAPI Microservice: /health and /search with CORS, background index load, and App Runner-ready Docker Compose.
Interactive Playground: Token heatmap UI to visualize which code tokens ColBERT aligns to your query.
Deploy Scripts: AWS App Runner + ElastiCache / EFS index storage without rebuilding the image for every corpus update.
Dependency Management: Ready-to-use UV and pip lockfiles for deterministic builds.

1REPO_URL=https://github.com/huggingface/transformers uv run python src/main.py

Portfolio-Ready Documentation

README.md + TUTORIAL.md: Architecture diagrams, indexing/serving walkthroughs, and production goals designed for GitHub showcase.
Smoke Tests: Compile + route checks, plus live search scripts against Hugging Face Transformers.

1docker-compose up --build

Tutorial Summary

Tutorial: CodeContext — Low-Latency Neural Code Search Engine What We’ll Build - The System Architecture

System Architecture

Retrieval Pipeline

Essential Source Flow Repository Ingestion Code Curation & Chunking ColBERT Retrieval Retrieval-Augmented Answering FastAPI Inference Service Configuration Run the System Evaluation Deployment Smoke Test

Tutorial: CodeContext — Low-Latency Neural Code Search Engine

What We’ll Build - The System Architecture

In this module, we’ll implement CodeContext: a code-aware RAG framework that retrieves relevant source-code snippets from a GitHub repository and serves them through a FastAPI search endpoint.

The workflow begins when a developer submits a natural-language query such as “How is retry logic handled?” The indexing pipeline downloads a GitHub repository, extracts supported code files, chunks classes and functions, and stores the chunks in a ColBERT-style retrieval index. The FastAPI backend then loads the index, checks Redis for cached results, retrieves matching chunks, and returns the answer candidates to the user.

◼ System Architecture

Kernel Labs | Kuriko IWAI | kuriko-iwai.com

Figure A. CodeContext system architecture — clients, edge/API gateway, FastAPI compute, Redis cache, ColBERT index / object / eval stores, and GitHub as the source corpus.

◼ Retrieval Pipeline

Kernel Labs | Kuriko IWAI | kuriko-iwai.com

Figure B. CodeContext retrieval pipeline — indexing workflow (src/main.py) and serving workflow (app.py + Redis HIT/MISS → ColBERT → ranked snippets).

Essential Source Flow

The module has one indexing path and one serving path:

1zip_bytes = fetch_repository_zip(repo_url=repo_url, branch=branch)
2chunks = chunk_source_code_from_zip(zip_bytes)
3pylate_model, pylate_index = index_codebase_pylate(chunks)
4

At serving time, /search checks Redis and then calls the ColBERT index:

1cache_key = f"search_cache:{q}"
2results = RAG.search(query=q, k=5)
3

Shipping AI Systems?

I help teams design and deploy scalable ML / RAG / LLM pipelines and MLOps infrastructure.

Or explore:

Dive deeper 👉 Research Archive
Learn by building 👉 AI Engineering Masterclass
Try it live 👉 Playground

Repository Ingestion

The data pipeline starts by downloading a GitHub repository as a zip archive. This avoids cloning the repo manually and lets the system ingest any public repository from a URL.

1def fetch_repository_zip(repo_url: str, branch: str = "main", timeout: int = 30) -> bytes:
2    api_url = repo_url.rstrip("/").replace("github.com", "api.github.com/repos")
3    api_url = f"{api_url}/zipball/{branch}"
4
5    response = requests.get(api_url, timeout=timeout)
6    response.raise_for_status()
7    return response.content
8

Run the ingestion pipeline with the default repository:

1uv run python src/main.py
2

Or override the target:

1REPO_URL=https://github.com/owner/repo REPO_BRANCH=main uv run python src/main.py
2

Code Curation & Chunking

Before retrieval can work, raw files must be converted into meaningful searchable units. Instead of embedding an entire repository as one document, the system chunks code around functions, classes, methods, and fallback text windows.

The chunker supports common source-code extensions:

1EXTENSION_MAP = {
2    "py": "python",
3    "js": "javascript",
4    "ts": "typescript",
5    "go": "go",
6    "rs": "rust",
7    "java": "java",
8    "cpp": "cpp",
9    "c": "c",
10}
11

The chunking process uses three strategies:

Tree-sitter parsing: Extracts structured function, class, and method definitions.

Regex fallback: Finds common declaration patterns when Tree-sitter fails.

Sliding window fallback: Splits long files into overlapping line windows.

Each chunk stores both source text and metadata:

1{
2    "content": "File: app.py\nLang: python\nType: function_definition\n\n...",
3    "metadata": {
4        "type": "function_definition",
5        "file": "app.py",
6        "line_start": 123,
7    },
8}
9

ColBERT Retrieval

Most embedding systems compress a whole document into one vector. ColBERT uses late interaction: it embeds query tokens and document tokens separately, then scores each query token against its best matching document token.

The high-level score is:

1score(query, document) = sum over query tokens of max matching document-token similarity
2

In code, the project creates a lightweight ColBERT model and a Voyager index:

1model = models.ColBERT(
2    model_name_or_path="lightonai/answerai-colbert-small-v1",
3    trust_remote_code=True,
4)
5
6index = indexes.Voyager(
7    index_folder="pylate-index",
8    index_name="code_base",
9    override=True,
10    embedding_size=96,
11)
12

Then it encodes and indexes the chunks:

1contents = [chunk["content"] for chunk in chunks]
2document_embeddings = model.encode(contents, is_query=False, batch_size=16)
3index.add_documents(documents_ids=contents, documents_embeddings=document_embeddings)
4

Retrieval-Augmented Answering

At query time, the retriever embeds the user question and returns the top matching chunks:

1def get_chunks(self, question: str, k: int = 3) -> list[str]:
2    query_embedding = self.model.encode([question], is_query=True)
3    results = self.retriever.retrieve(queries_embeddings=query_embedding, k=k)
4    return [self._extract_document(result) for result in results[0]]
5

The retrieved code can then be passed to an LLM as context:

1prompt = f"Code Context:\n{context_text}\n\nQuestion: {question}\nDetailed Answer:"
2response = self.llm.invoke(prompt)
3

Shipping AI Systems?

I help teams design and deploy scalable ML / RAG / LLM pipelines and MLOps infrastructure.

Or explore:

Dive deeper 👉 Research Archive
Learn by building 👉 AI Engineering Masterclass
Try it live 👉 Playground

FastAPI Inference Service

The serving layer exposes the retrieval system through two endpoints:

1GET /health
2GET /search?q=<query>
3

When the API starts, it connects to Redis if available and loads the configured index in the background:

1asyncio.create_task(load_index_background())
2

The search endpoint follows a simple inference workflow:

Redis cache lookup: Return cached results for repeated queries.

Index readiness check: Return an error if the search index is not loaded.

ColBERT search: Retrieve the top matching code chunks.

Cache write: Store fresh results for one hour.

1cache_key = f"search_cache:{q}"
2results = RAG.search(query=q, k=5)
3await redis_client.setex(cache_key, 3600, json.dumps(results, default=json_default))
4

Configuration

Create a .env file:

1REDIS_HOST=localhost
2REDIS_PORT=6379
3COLBERT_INDEX_PATH=.ragatouille/colbert/indexes/CodeBaseIndex
4CORS_ORIGINS=http://localhost:8000,https://kuriko-iwai.com
5ENABLE_TRACELOOP=false
6OPENROUTER_API_KEY=...
7

Optional Redis cache:

1brew install redis
2brew services start redis
3

Run the System

Install dependencies:

1uv sync
2

Build or test retrieval:

1uv run python src/main.py
2

Start the API:

1uv run python app.py
2

Or start with Docker:

1docker-compose up --build
2

Check the service:

1curl "http://127.0.0.1:8000/health"
2

Search the codebase:

1curl "http://127.0.0.1:8000/search?q=where+is+retry+logic+handled"
2

Evaluation

The full pipeline can optionally generate synthetic questions and evaluate retrieval-augmented answers with RAGAS:

1RUN_RAGAS_EVAL=true uv run python src/main.py
2

The project tracks metrics such as context precision, context recall, faithfulness, and answer relevancy.

Shipping AI Systems?

I help teams design and deploy scalable ML / RAG / LLM pipelines and MLOps infrastructure.

Or explore:

Dive deeper 👉 Research Archive
Learn by building 👉 AI Engineering Masterclass
Try it live 👉 Playground

Deployment

The production setup has two core components:

FastAPI microservice: Serves /health and /search over HTTP.
Redis cache: Reduces repeated retrieval latency for identical queries.

For containerized local deployment:

1docker-compose up --build
2

For AWS deployment, keep the index on persistent storage such as EFS so the service can update retrieval data without rebuilding the container image.

Smoke Test

Run:

1uv run bash scripts/test.sh
2

This compiles the Python files and verifies that /health and /search are registered.

The Project Kit

The Retrieval Pipeline

A modular Python codebase structured for production code intelligence:

AST / Tree-sitter Chunking: Structural function- and class-level indexing across py, js, ts, go, and more—with regex and sliding-window fallbacks.
ColBERT Late Interaction: Token-level MaxSim scoring via RAGatouille / PyLate for fine-grained code matching that bi-encoders miss.
Redis Semantic Cache: Sub-10ms cache hits for recurrent architectural queries with TTL write-back after ColBERT inference.
RAGAS + OpenLLMetry: Context precision/recall evaluation and span-level traces across Redis lookup and retrieval.

The Full-Stack Serving Layer

An entire system to index repositories and serve low-latency search:

FastAPI Microservice: /health and /search with CORS, background index load, and App Runner-ready Docker Compose.
Interactive Playground: Token heatmap UI to visualize which code tokens ColBERT aligns to your query.
Deploy Scripts: AWS App Runner + ElastiCache / EFS index storage without rebuilding the image for every corpus update.
Dependency Management: Ready-to-use UV and pip lockfiles for deterministic builds.

1REPO_URL=https://github.com/huggingface/transformers uv run python src/main.py

Portfolio-Ready Documentation

README.md + TUTORIAL.md: Architecture diagrams, indexing/serving walkthroughs, and production goals designed for GitHub showcase.
Smoke Tests: Compile + route checks, plus live search scripts against Hugging Face Transformers.

1docker-compose up --build
